About This Product
The KGZ165(1.0)-G-5620 250g is a precision spring-loaded switch probe designed for reliable switching, electrical contact, and functional testing applications. It provides consistent mechanical movement and stable electrical contact during repeated test cycles.
With a 5.00 mm full stroke, 4.00 mm rated stroke, and approximately 250 gf spring force, the probe is suitable for applications requiring controlled contact pressure and dependable switching performance. Gold-plated conductive components and PEEK insulation provide durability and reliable electrical isolation.
| Specification | Details |
|---|---|
| Product Type | Switch Probe |
| Model | KGZ165(1.0)-G-5620 |
| Contact Diameter | Ø1.00 mm |
| Full Stroke | 5.00 mm |
| Rated Stroke | 4.00 mm |
| Switching Distance | 1.50 mm |
| Spring Force | 250 ± 50 gf |
| Spring Force | Approx. 2.5 N |
| Plunger | BeCu, Gold-Plated |
| Barrel | Brass, Gold-Plated |
| Spring | SWP, Gold-Plated |
| Insulation | PEEK |
Applications
-
- Switch Testing
- Electrical Contact Testing
- Functional Testing
- Electronic Test Fixtures
- PCB Testing
- Automated Testing Equipment
- Control Panel Testing
- Production Line Testing
- Electronic Assembly Testing
- Custom Test Fixtures
